Introduction

Using hands-on exercises representing real-world, industry-specific design scenarios, students explore the fundamental concepts and workflows for creating 3D models using AutoCAD. Students learn how to create and modify both solid and surface models. This course also teaches students how to present their designs while they are still being created, using visualization tools such as visual styles, model walk and fly through, materials, and lighting. Students also learn how to output 3D models from AutoCAD to either paper or a distributive electronic version.

Who Should Attend

Existing users of 2D AutoCAD wanting to learn ways to become more productive and professional using the workflows of 3D modeling, surfacing and presentation.

Outline

  • Introduction to 3D
  • XYZ-Plane
  • Types of 3d Models
  • Changing the Model Display – Visual Styles
  • View Cube ( Parallel and Perspective modes )
  • Setting Model Viewports
  • Spaceware and 3d Printing Solid Modelling
  • Working in 3D Space
  • Changing the Model Position
  • Editing Solid Models
  • Extracting Geometry from Solid Models
  • Reporting Information from 3D Solid
  • Importing 3D Models
  • SKP Import Addin
  • Mesh Modelling
  • Surfacing
  • Visualization
  • Autodesk 123D/FormIt
